The Apache HTTP Server, colloquially called Apache, is a free and open-source cross-platform web server. This article explains briefly how to set up Apache as a reverse proxy to a web site in an internal network.

To set the expectations in this article. I'm not going to explain you how to install Apache web server or how to get it operational on your system. There are thousands of tutorials including my own Accessing your web server via IPv6 on the Internet that already cover that step.

In case more information about the configuration directives used below is needed, I recommend to consult the official documentation of a particular keyword.

The scenario

I have a web site running on a system in an internal network. This could be either a full-fledged Windows/Linux server or an IoT device running on a single board computer (SBC), like i.e. a Raspberry Pi, an Arduino, ESP8266 chipset.

A reverse proxy taking requests from the Internet and forwarding them to servers in an internal network. Source: Wikipedia

Now, I want to enable access from the Internet to that internal server using Apache.

Configuring Apache as reverse proxy

In order to complete our task we need to look into the features of the mod_proxy module for Apache. Here, we get a directive called ProxyPass which does the job as expected. According to Apache's Reverse Proxy Guide the simplest example proxies all requests ("/") to a single backend:

ProxyPass "/"  "http://www.example.com/"

Additionally, to hide any reference to the system on the internal network it is required to specify the directive ProxyPassReverse to modify certain HTTP header values in the response, and use the proxy data instead.

Following is a working example of how to set up a virtual host in Apache that provides reverse proxy capabilities.

<VirtualHost *:80>
        ServerName mediacentre.kirstaetter.name

        ProxyRequests On
        ProxyPreserveHost On
        ProxyVia full

        <Proxy *>
                Order deny,allow
                Allow from all
        </Proxy>

        ProxyPass               /       http://10.0.240.4:8080/
        ProxyPassReverse        /       http://10.0.240.4:8080/
</VirtualHost>

The host system on IP address 10.0.240.4 is part of an OpenVPN infrastructure and therefore accessible from the proxy system.

Multiple proxies possible

No problem with Apache. You can configure and run as many reverse proxies as would like to. One has to pay attention to avoid overlaps either via ServerName directive or by using different port numbers to bind to. Although I have only one reverse proxy running on Apache I configured multiple scenarios using nginx. More details are described in Using nginx as reverse proxy.

Do you have any interesting use cases or active configurations of Apache as reverse proxy? If yes, please use the comment section below give me and other readers more details. Thanks!
